Features:
- Highvoltageresponse, stable during most of the lifetime of the application
- Reliable Performance
- Child-Safe Markings & Retail Packaging
- Lowself-discharge with long operating life (<1% after 1 year of storage at + 20 °C)
- Excellent resistance to corrosion
- Designed to meet all major quality, safety and environment standards:
- Safety: IEC 60086-4
- Transport: UN 38.3
- RoHS and REACH compliance
- Quality: ISO 9001, Duracell World Class Continuous Program
Electrical Characteristics:
- Nominal capacity (15 k Cont., 2.0 V cut-off) - 265mAh
- Open circuit voltage (at + 20 °C) - 3.2V
- Standard Continuous Discharge Current - 0.3mA
- Maximum Continuous Discharge Current - 3mA
- Maximum Pulse Discharge Current at 1 sec - 50mA
- Nominal Energy - 745mWh
- AC Impedance @ 1kHz - 11Ω
TYPICAL APPLICATIONS
- Medical devices
- Security devices
- Fitness devices
- Watches
- Calculators
- Wireless sensors
- Key-Fobs & Trackers
