CYP HDBaseT Splitter 1x4. 1x HDMI Input, 1x HDMI Output, 3x

Model: CHDBT-1H3CL

CYP HDBaseT Splitter 1x4. 1x HDMI Input, 1x HDMI Output, 3x HDBaseT up to 60m Outputs. 4K2K Resolution & 3D Support. 2-Way IR control.

CHDBT-1H3CL - HDBaseT-Lite 1x4 HDMI over CAT5e/6/6A Transmitter-Splitter

Features:

HDMI with 3D & 4K2K supported, HDCP and DVI compliant
The HDMI and CAT5e/6/6A outputs are playing the same source simultaneously
Supports data rate from 250Mbps up to 3Gbps
Supports a wide range of PC resolutions from VGA to WUXGA and HDTV resolutions up to 4K2K (3840x2160@30Hz & 4096x2160@24Hz)
Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission (32-192kHz sample rate)
Supports distances up to 60 meters through CAT5e/6/6A cables
Can select Standard or TV EDID
Supports USB service port
Supports Bi-directional IR control
The 3D signal display follows by display/TV's EDID
Recommended receiver: CH-506RXL
