20M LCAPC to LCAPC G657A1 OS1/OS2 Compliant Armoured Duplex Singlemode

Model: FLA-APCLCLC-20

DYNAMIX 20M LCAPC to LCAPC G657A1 Armoured Duplex Singlemode Fibre Lead Yellow 3.3mm LSZH Jacket Yellow 3.3mm LSZH Jacket

AVAILABLE SIZES

Choose your required cable length

5m 7.5m 10m 12.5m 15m 20m 25m 30m 40m 50m

DESCRIPTION

Built for Reliable Fibre Connectivity.

The DYNAMIX Armoured Duplex Single-Mode Fibre Lead features LC/APC connectors at both ends & OS2 G657A1 bend-insensitive fibre for reliable, low-loss optical transmission.

Its 3.3mm round construction combines steel wire armour, Kevlar reinforcement & a yellow LSZH jacket to provide added mechanical protection while maintaining flexibility for tight cable routing.

LC/APC Duplex OS2 G657A1 Armoured LSZH

DYNAMIX LC/APC Duplex Armoured Fibre Lead

KEY FEATURES

01 / CONNECTIVITY

LC/APC Duplex

LC/APC connectors at both ends for dependable connections.

02 / FIBRE

OS2 G657A1

Bend-insensitive single-mode fibre for low-loss transmission.

03 / PROTECTION

Steel Armoured

Steel wire armour for additional mechanical protection.

04 / STRENGTH

Kevlar Reinforced

Kevlar yarn improves tensile strength & pull resistance.

05 / JACKET

3.3mm LSZH

Yellow Low Smoke Zero Halogen outer jacket.

06 / PERFORMANCE

Low Signal Loss

Insertion ≤0.3dB & return loss ≥60dB.

DYNAMIX LC/APC Duplex Fibre Cable Construction Infographic

Select the infographic to enlarge

IDEAL APPLICATIONS

FTTH Data Centres Telecommunications Structured Cabling High-Density Installations Indoor Networks

SPECIFICATIONS

Select a category to view its technical details

GENERAL & CONNECTIVITY

Product Type Armoured Fibre Optic Patch Lead

Connector A LC/APC Duplex

Connector B LC/APC Duplex

Fibre Mode Single-Mode

Classification OS2

Fibre Standard G657A1

Fibre Count 2 Core (Duplex)

CABLE CONSTRUCTION

Cable Diameter 3.3 ±0.2mm

Construction Round Armoured

Armour Material Steel Wire

Strength Member Kevlar Yarn

Outer Jacket LSZH

Jacket Colour Yellow (PMS 122C)

Connector Colour Green

OPTICAL & MECHANICAL PERFORMANCE

Insertion Loss ≤0.3dB

Return Loss ≥60dB

Attenuation @ 1310nm ≤0.35dB/km

Attenuation @ 1550nm ≤0.22dB/km

Minimum Bend Radius Static: 10D
Dynamic: 20D

Tensile Strength Long Term: 80N
Short Term: 150N

Crush Resistance Long Term: 500N/100mm
Short Term: 2000N/100mm

ENVIRONMENT & COMPLIANCE

Installation Temperature -10°C to +60°C

Operating Temperature -15°C to +70°C

Storage Temperature -15°C to +70°C

Compliance RoHS, REACH, TSCA, Prop 65

DYNAMIX Fibre Connectivity

Armoured duplex single-mode fibre lead with protective LC/APC dust covers.

Packaging shown for reference. Length varies by model.
