12.5M LCAPC to LCAPC G657A1 OS1/OS2 Compliant Armoured Duplex Singlemode

Model: FLA-APCLCLC-12-5

DYNAMIX 12.5M LCAPC to LCAPC G657A1 Armoured Duplex Singlemode Fibre Lead Yellow 3

AVAILABLE SIZES

Choose your required cable length

5m 7.5m 10m 12.5m 15m 20m 25m 30m 40m 50m

DESCRIPTION

Built for Reliable Fibre Connectivity.

The DYNAMIX Armoured Duplex Single-Mode Fibre Lead features LC/APC connectors at both ends & OS2 G657A1 bend-insensitive fibre for reliable, low-loss optical transmission.

Its 3.3mm round construction combines steel wire armour, Kevlar reinforcement & a yellow LSZH jacket to provide added mechanical protection while maintaining flexibility for tight cable routing.

LC/APC Duplex OS2 G657A1 Armoured LSZH

DYNAMIX LC/APC Duplex Armoured Fibre Lead

KEY FEATURES

01 / CONNECTIVITY

LC/APC Duplex

LC/APC connectors at both ends for dependable connections.

02 / FIBRE

OS2 G657A1

Bend-insensitive single-mode fibre for low-loss transmission.

03 / PROTECTION

Steel Armoured

Steel wire armour for additional mechanical protection.

04 / STRENGTH

Kevlar Reinforced

Kevlar yarn improves tensile strength & pull resistance.

05 / JACKET

3.3mm LSZH

Yellow Low Smoke Zero Halogen outer jacket.

06 / PERFORMANCE

Low Signal Loss

Insertion ≤0.3dB & return loss ≥60dB.

DYNAMIX LC/APC Duplex Fibre Cable Construction Infographic

Select the infographic to enlarge

IDEAL APPLICATIONS

FTTH Data Centres Telecommunications Structured Cabling High-Density Installations Indoor Networks

SPECIFICATIONS

Select a category to view its technical details

GENERAL & CONNECTIVITY

Product Type Armoured Fibre Optic Patch Lead

Connector A LC/APC Duplex

Connector B LC/APC Duplex

Fibre Mode Single-Mode

Classification OS2

Fibre Standard G657A1

Fibre Count 2 Core (Duplex)

CABLE CONSTRUCTION

Cable Diameter 3.3 ±0.2mm

Construction Round Armoured

Armour Material Steel Wire

Strength Member Kevlar Yarn

Outer Jacket LSZH

Jacket Colour Yellow (PMS 122C)

Connector Colour Green

OPTICAL & MECHANICAL PERFORMANCE

Insertion Loss ≤0.3dB

Return Loss ≥60dB

Attenuation @ 1310nm ≤0.35dB/km

Attenuation @ 1550nm ≤0.22dB/km

Minimum Bend Radius Static: 10D
Dynamic: 20D

Tensile Strength Long Term: 80N
Short Term: 150N

Crush Resistance Long Term: 500N/100mm
Short Term: 2000N/100mm

ENVIRONMENT & COMPLIANCE

Installation Temperature -10°C to +60°C

Operating Temperature -15°C to +70°C

Storage Temperature -15°C to +70°C

Compliance RoHS, REACH, TSCA, Prop 65

DYNAMIX Fibre Connectivity

Armoured duplex single-mode fibre lead with protective LC/APC dust covers.

Packaging shown for reference. Length varies by model.
